12 | English
2 609 932 794 | (21.3.11) Bosch Power Tools
Noise/Vibration Information
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly
reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from
the effects of vibration such as: maintain the tool and the acces-
sories, keep the hands warm, organisation of work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
02.03.2011
Assembly
Changing the Tool (see figure A)
f Before any work on the machine itself, pull the mains
plug.
Pull off the screwing-depth stop 4 toward the front. Pull out
the screwdriver bit 1. If required, the universal bit holder 10
can also be pulled off and replaced.
After changing the tool, reattach the screwing-depth stop 4.
Operation
Starting Operation
f Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.
Reversing the Rotational Direction
The rotational direction switch 8 is used to reverse the rota-
tional direction of the machine. However, this is not possible
with the On/Off switch 7 actuated.
Right rotation: For driving in screws, push the rotational di-
rection switch 8 left to the stop.
Left rotation: Push the rotational direction switch 8 right to
the stop (for unscrewing screws).
Switching On and Off
To start the machine, press the On/Off switch 7 and keep it
pressed.
To lock the pressed On/Off switch 7, press the lock-on button
6.
To switch off the machine, release the On/Off switch 7 or
when it is locked with the lock-on button 6, briefly press the
On/Off switch 7 and then release it.
Tool holder ¼" hexagon socket ¼" hexagon socket ¼" hexagon socket
Max. screw dia. mm 6 6 6
Weight according to EPTA-Procedure 01/2003 kg 1.5 1.4 1.4
Protection class /II /II /II
Screwdriver GSR 6-25 TE
Professional
GSR 6-45 TE
Professional
GSR 6-60 TE
Professional
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Measured sound values determined according to EN 60745. 3 601 ... D45 0.. D45 1.. D45 2..
Typically the A-weighted noise levels of the product are
Sound pressure level
Sound power level
Uncertainty K=
Wear hearing protection!
dB(A)
dB(A)
dB(A)
81
92
3
79
90
3
81
92
3
Vibration total values (triax vector sum) determined according to EN 60745:
Screwdriving without impact:
Vibration emission value a
h
=
Uncertainty K =
m/s 2
m/s 2
<2.5
1.5
<2.5
1.5
3.3
1.5
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
