2
ASRock H61M-DPS Motherboard
Motherboard Layout
English
1
Power Fan Connector (PWR_FAN1)
14
SATA2 Connector (SATA_0)
2
ATX 12V Power Connector (ATX12V1)
15
SATA2 Connector (SATA_2)
3
1155-Pin CPU Socket
16
USB 2.0 Header (USB6_7)
4
CPU Fan Connector (CPU_FAN1)
17
USB 2.0 Header (USB4_5)
5
2 x 240-pin DDR3 DIMM Slots
18
Consumer Infrared Module Header (CIR1)
(Dual Channel: DDR3_A1, DDR3_B1)
19
COM Port Header (COM1)
6
ATX Power Connector (ATXPWR1)
20
Print Port Header (LPT1)
7
System Panel Header (PANEL1)
21
Front Panel Audio Header (HD_AUDIO1)
8
Intel H61 Chipset
22
PCI Slot (PCI1)
9
Chassis Speaker Header (SPEAKER1)
23
Chassis Intrusion Header (CI1)
10
32Mb SPI Flash
24
Clear CMOS Jumper (CLRCMOS1)
11
SATA2 Connector (SATA_3)
25
PCI Express 2.0 x1 Slot (PCIE2)
12
SATA2 Connector (SATA_1)
26
PCI Express 3.0 x16 Slot (PCIE1)
13
Chassis Fan Connector (CHA_FAN1)
Intel
H61
A
T
XPWR1
DDR3_A1
(64
b
it,
240-pin
module)
DDR3_B1
(64
b
it,
240-pin
module)
PCIE1
Top:
RJ-45
USB 2.0
T: USB2
B: USB3
PS2
Keyboard
USB 2.0
T: USB0
B: USB1
Top:
LINE
IN
Center:
FRONT
Bottom:
MIC
IN
Super
I/O
CMOS
Battery
PWR_FAN1
CPU_FAN1
H61M-DPS
LAN
PHY
1
HD_AUDIO1
AUDIO
CODEC
32Mb
BIOS
1
SPEAKER1
3
4
5
6
12
22
21
SATA_0
SATA_1
SATA_2
SATA_3
PS2
Mouse
CHA_FAN1
USB6_7
1
X
Fast
LAN
X
Fast USB
RoHS
COM1
1
LPT1
HDLED
R
ESET
PLED
PWRBTN
PANEL1
1
X
Fast RAM
ATX12V1
USB4_5
CIR1
1
1
VGA1
DVI1
1
2
7
8
9
13
15
17
18
19
20
10
11
14
23
16
PCIE2
PCI1
CLRCMOS1
1
CI1
1
24
26
25
