Assembly, Installation and Operating Instructions
SAFETY SUMMARY
The following recommendations are made for the safe
installation and use of the PreciseR
X
TM Pediatric Flow-
meter:
Federal law restricts this device to sale by or on
the order of a physician.
DO NOT install this equipment without first read-
ing and understanding this instruction sheet. If
you are unable to understand these instructions,
contact a healthcare professional, dealer or
technical personnel if applicable before
attempting to install this equipment - otherwise,
injury or damage may occur.
DO NOT smoke while using oxygen.
DO NOT use oxygen in the presence of flames,
sparks, or glowing object.
Oxygen rapidly accelerates combustion.
Use of this product with any oxygen concentra-
tor other than the models listed in this
documentation is NOT recommended. Such un-
authorized usage may result in inaccurate
oxygen delivery and may be hazardous to the
patient.
The PreciseR
X
TM Pediatric Flowmeter is
applicable to Oxygen Concentrator Models
IRC301, IRC301O2, IRC3LX, IRC501, IRC501O2,
IRC5LX , IRC5LXO2 and IRC6LXO2.
The flowmeters are designed for an input pres-
sure of 5 psi (34.5 kPa) ONLY.
Invacare recommends that Crush-Proof
oxygen tubing (supplied by Invacare) be used
exclusively with this product and NOT exceed
25 ft. (7.6 meters) in total length from either the
Humidifier Bottle Adapter to the patient OR the
Pediatric Flowmeter to the patient if the Humidi-
fier Bottle is NOT used.
DO NOT disassemble. Only authorized or
factory-trained personnel should perform
disassembly procedures.
PEDIATRIC FLOWMETER
ACCESSORY KIT - MODEL NO.
IRCPF16 PARTS LIST
. Y T Q M E T I
Flowmeter Stand
1
Crush-Proof Tubing (CP) - 25 ft. (Max.)
(7.5 m) 1
Crush-Proof Tubing - 7 ft. (2.1 m) total 2
Humidifier Bottle Adapter 1
Humidifier Bottle 1
Connector 1
Packaging (Carton) 1
Instructions 1
SPECIFICATIONS
Input Pressure Rating: 5 + 0.5 psi
(34.5 + 3.45 kPa)
Oxygen Output: 0-3/4 L/min.
Oxygen Input: 2 L/min.
Flow Adjustable
in increments: 1/16 L/min.
Flow Accuracy: + 10% of full scale
Width: 4.7-inches (11.94 cm.)
Height: 5.7-inches (14.48 cm.)
Depth: 4.7-inches (11.94 cm.)
Weight: 1.86 lbs. (0.8 kg.)
Shipping Weight: 5.0 lbs. (2.3 kg.)
INVACARE PRECISER
X
TM PEDIATRIC
FLOWMETER MODEL NO. IRCPF16
HANDLING PROCEDURES
Shipping and Transportation
Instructions
The shipping container for the Pediatric Flowmeter has
been designed to assure maximum protection for the
flowmeter.
If the flowmeter is to be reshipped, it should be packed in
the same carton. Extra cartons are available from Invac-
are.
Unpacking
1. Check for any obvious damage to the carton or
its contents. If damage is evident, notify your
Carrier/ Dealer for further instruction.
2. Remove all the loose packing from the carton.
