Fig. 3-3 – Activeforever AutoCloser Automatic Garage Door Closer User Manual
Page 11
11
The Autocloser must be mounted in a position with the infrared sensors aimed straight to-
ward the reflector (Fig. 3-2). In order to accomplish this on all of the different shaped ga-
rage door openers available, the Autocloser box will always be mounted to the power
head assembly.
TIP: The Autocloser will need to be mounted at least 2 inches left or right of the center of
the garage door opener to facilitate lining up the box and reflector.
Switch the Autocloser
to setup mode using the ON/OFF/SETUP switch on the back of the
Autocloser unit (Fig. 3-3).
Fig. 3-2
The infrared
sensor should
be in line with
the reflector.
Position the Autocloser on
the garage door opener
m otor housing with the label
side down.
Fig. 3-3
