Since continuous transmission is prohibited, you only hear your baby when it makes sounds.
The antennas on both units are fixed. Do not pull at them or try to remove them.
Preparing for use
You can use the baby monitor from the mains or on batteries.
Mains operation
1
Put the small plug in the baby unit and put the adapter in a wall socket. (Fig. )
Put the small plug in the parent unit and put the adapter in a wall socket. (Fig. )
Battery operation
Even if you do not intend to use the baby monitor on batteries, we advise you to insert batteries
into both units. This guarantees automatic back-up in case of mains failure.
Both the parent unit and the baby unit run on four 1.5-volt R6 AA batteries. We strongly advise you
to use Philips LR6 PowerLife batteries.
Replace the batteries when the power-on light blinks red when you operate the baby monitor on
batteries.
Make sure your hands and the units are dry when you insert the batteries.
Note:Do not mix old and new batteries or different types of batteries.
Note:Remove the batteries if you are not going to use the baby monitor for a month or more.
Note:If the batteries are left in the unit when it is operated on mains power, check them for leakage
every six months.
Baby unit
1
Unlock the battery compartment lid by turning the locking knob with a coin. Then remove
the lid. (Fig. )
Insert four 1.5-volt AA batteries. (Fig. 5)
Make sure the + and - poles of the batteries point in the right direction.
Close the battery compartment lid by turning the locking knob with a coin.
Parent unit
1
Turn the locking knob in the bottom a quarter turn (1) and slide the battery compartment
lid downwards to remove it (). (Fig. 6)
Insert four 1.5-volt AA batteries. (Fig. 7)
Make sure the + and - poles of the batteries point in the right direction.
Slide the battery compartment lid back onto the battery compartment (1) and turn the
locking knob in the bottom a quarter turn to fasten the lid (). (Fig. 8)
using the appliance
1
Place the two units in the same room to test the connection. (Fig. 9)
Make sure the baby unit is at least 1 metre/3 feet away from the parent unit.
Press the on/off button to switch on the baby unit. (Fig. 10)
The power-on light starts to burn green.
Turn the volume control to switch on the parent unit and to set the volume to the level you
prefer. (Fig. 11)
The power-on light starts to burn green.
,
,
,
,
