3.0. Smart Card Support
3.1. MCU Cards
The ACR38x is a PC/SC-compliant smart card reader that supports ISO 7816 Class A, B and C (5 V,
3 V, and 1.8 V) smart cards. It also works with MCU cards following the T=0 and T=1 protocol.
The card ATR indicates the specific operation mode (TA2 present; bit b5 of TA2 must be 0) and when
that particular mode is not supported by the ACR38x, the reader will reset the card to a negotiable
mode. If the card cannot be set to negotiable mode, the reader will then reject the card.
When the card ATR indicates the negotiable mode (TA2 not present) and communication parameters
other than the default parameters, the ACR38x will execute the PPS and try to use the communication
parameters that the card suggested in its ATR. If the card does not accept the PPS, the reader will
use the default parameters (F=372, D=1).
For the meaning of the aforementioned parameters, please refer to ISO 7816-3.
3.2. Memory-based Smart Cards
The ACR38x works with several memory-based smart cards such as:
• Cards following the I2Cbus protocol (free memory cards) with maximum 128 bytes page with
capability, including:
o Atmel: AT24C01/02/04/08/16/32/64/128/256/512/1024
o SGS-Thomson: ST14C02C, ST14C04C
o Gemplus: GFM1K, GFM2K, GFM4K, GFM8K
• Cards with secure memory IC with password and authentication, including:
o Atmel: AT88SC153 and AT88SC1608
• Cards with intelligent 1k bytes EEPROM with write-protect function, including:
o Infineon: SLE4418, SLE4428, SLE5518 and SLE5528
• Cards with intelligent 256 bytes EEPROM with write-protect function, including:
o Infineon: SLE4432, SLE4442, SLE5532 and SLE5542
• Cards with ‘104’ type EEPROM non-reloadable token counter cards, including:
o Infineon: SLE4406, SLE4436, SLE5536 and SLE6636
