Y1-03-0141F 7
Figure 3- URP-
102 Point Pad™ Functions
URP-102 Point Pad Functions

Press the ON/OFF button to turn the lights ON or OFF.

Press the SPEED button to toggle between High and Low rotation speeds.

Press the Right or Left Arrows to rotate the Searchlight in that direction.

Press the Up or Down Arrows to raise or lower the Searchlight-beam.

To activate the XRCiZ
™ feature, press and hold the ON/OFF button for
greater than 5 seconds. The green LED indicates XRCiZ
™ feature is enabled.

To deactivate the XRCiZ
™ feature, Press and hold the ON/OFF button for
greater than 5 seconds. The red LED indicates XRCiZ
™ feature is disabled.

An LED blinking red / green indicates that the XRCiZ
™ feature is now
“exercising” the Searchlight.
NOTE: XRCiZ
™ feature is only available when paired with a URC-102 Master
Controller.
