FES6850
Fanless Embedded Controller comes with
Intel Celeron M 600MHz Processor
1.3 Specifications
System
z
CPU: Intel® Celeron® M 600MHz/ 1.3GHz Processor
z
Construction: Rugged Aluminum Alloy chassis
z
System Memory: DDR SODIMM x 1, Max. 512MB
z
VGA: DB-15 VGA connector
z
Keyboard/Mouse: PS/2 Keyboard & Mouse
z
Ethernet: 0/100Base-TX RJ-45 connector x 1
z
SSD: Internal Type II CompactFlash™ slot x 1
z
Card Reader: CompactFlash™, SD/ MMC/ MS/ XD
z
Device Bay (Optional): CD-ROM & 2.5"HDD Kit, 2 x 2.5" HDD Kit, 3.5" HDD Kit
z
Serial Port: 1 x RS-232, 1 x RS-232/422/485
z
Audio: MIC / Line In / Line Out by expansion cable
z
USB: 3 USB 2.0 ports
z
DVI: DVI connector x 1
z
Watchdog Timer: Generate a time-out System reset, setting via software
z
Power Supply: A1/A2 Version-AC Input:
External Power Adapter; Input Voltage:
100V AC~240V AC @ 50 ~ 60Hz;
A3/A4 Version-DC Input: 9V DC~30V DC
z
System Control: Power on / off switch x 1; Reset button x 1
