Acnodes FES 2217 User Manual
Page 18

11. System Panel Header (9-pin PANEL1)
[refer to P. 14, No. 21]
This header accommodates several system front panel functions.
- PWRBTN (Power Switch)
- RESET (Reset Switch)
- PLED (System Power LED)
- HDLED (Hard Drive Activity LED)
12. 3W Audio AMP Output Wafer Header (4-pin SPEAKER 1)
[refer to P.14, No. 30]
Please connect the speaker to this header.
13. 4-Pin Power Connector (4-pin DC 12V1)
[refer to P.14, No. 4]
Please connect a DC 12V power supply to this connector.
