Acnodes FES 2217 - Manual (Page 12)

2, 10, & 11: COM Port 1, 2, 3 ( DB-9 ): RS-232/ 422/ 485
PIN RS-232 RS-422 RS-485
1 DCD# TX+ RTX+
2 RXD RX+ Not Used
3 TXD TX- RTX-
4 DTR# RX- Not Used
5 GND GND GND
6 DSR# Not Used Not Used
7 RTS# Not Used Not Used
8 CTS# Not Used Not Used
9 RI# Not Used Not Used
3. VGA Port (VGA 1)
4 & 5: LAN 1 & 2 (RJ-45)
PIN Definition PIN Definition
1 Lan_TX1+ 2 Lan_TX1-
3 Lan_TX2+ 4 Lan_TX3+
5 Lan_TX3- 6 Lan_TX2-
7 Lan_TX4+ 8 Lan_TX4-
6: Line-Out Connector
PIN Definition PIN Definition
1 LINE_OUT_Left 2 LINE_OUT_Right
3 AUDIO_AGND 4 AUDIO_AGND
5 LINE_IN_Left 6 LINE_IN_Right
7 AUDIO_AGND 8 AUDIO_AGND
9 Micro phone_IN1 10 Micro phone _IN2
8 & 9: USB Connector
PIN Signal PIN Signal
1 5V 5 5V
2 D- 6 D-
3 D+ 7 D+
4 GND 8 GND
