RMW 7190

19” 1440x900 Full HD Widescreen LCD

7U Rackmount Display Panel

< 1.3 > Installation

Step

1

¦

Mount the display panel with M6 screw set.

¦

M6 screw x 4 pcs required ( Left & right side ).

M6 screw sets are not provided.

Step

2

¦

Fix the LCD into the rack.
