Power connector



FPC5121 : DC power 10~30VDC (phoenix type)



1.2.3

System Specification

12.1

” TFT LCD



Heat Dispensing Design



Disk drive housing:



One 2.5

” SATA drive



Net Weight



2.48 Kgs (5.46 lb)



Dimension (Main Body Size)



327.5x 52.5 x 261.8mm



Operation Temperature



0℃ to 50℃(with W .T. DRAM/HDD in airflow condition)



Relative Humidity



10% to 95% @ 40 , Non-Condensing



Vibration



5 to 500 Hz, 2.0 G random for CF card



Power input



10~30VDC with phoenix power connector



External 60W AC Adapter

Power Input: 100VAC to 240VAC

Power Output: 12VDC, Max. 5A



NOTE: All specifications and images are subject to change without notice.

NOTE: If the operation temperature is higher than 35 , the wide temperature DRAM and HDD

are recommended to be used on the device.
