RPS1200

20” 1152 x 900 SUN LCD Monitor

1U Rackmount Display Panel

< Part 1 >

< 1.1 > Package Content

RPS1200 unit X 1

- 6ft VGA cable X 1
- Power cord X 1

- M6 screw, cage nut & cup washer X 8

The above package content is only for the pure model ( VGA and DVI-D only ).
It varies with options such as DC power.

< 1.2 > Structure Diagram

1

2

4

3

5

6

1

LCD panel

2

Installation Slide

3

LCD OSD membrane

4

Audio speaker

5

Carry handle to release the 2-pt lock

6

2-point lock
