Acnodes PCH 3591 User Manual
Page 30
[Enabled]
IDE Detect Time Out :
[35]
[0]
[5,10,15,20,25,30]
ATA(PI) 80Pin Cable Detection:
[Host & Device]
[Host]
[Device]
3.4.3 Super IO Configuration
BIOS SETUP UTILITY
Advanced
Configure Win627UHG Super IO Chipset
Allow BIOS to Select
Serial Port Base
Address.
Select Screen
Select Item
+- Charge Field F1
General Help F10
Save and Exit ESC
Exit
Serial Port1 Address
[3F8]
Serial Port2 Address
[2F8]
Serial Port3 Address
[3E8]
Serial Port3 IRQ
[IRQ4]
Serial Port3 Mode
[RS-485]
Serial Port4 Address
[2E8]
Serial Port4 IRQ
[IRQ3]
Serial Port5 Address
[238]
Serial Port5 IRQ
[IRQ5]
V02.61 © Copyright 1985-2006 American Mega trends , Inc.
Serial Port3 Mode:
COM3 Options:
[RS485 ]
[RS422]
[RS422] for RS422 Mode
[RS485] for RS485 Mode
