RP2117
17” 1920x1200 Full HD Widescreen LCD
1U Rackmount Display Panel
< Part 1 >
< 1.1 > Package Content
RP2117 unit X 1
- 6ft VGA cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the pure model ( VGA and DVI-D only ).
It varies with options such as SDI, HDMI, audio, touchscreen & DC power.
< 1.2 > Structure Diagram
1
4
2
5
3
6
1 LCD panel
2 Installation Slide
3 Audio speaker ( for HDMI or Audio option )
4 LCD OSD membrane
5 Carry handle to release the 2-pt lock
6 2-point lock
