< Part 1 >

< 1.1 > Package Content








< 1.2 > Structure Diagram






KDF8170 unit X 1

- 6ft D VI-D console cable X 1

( Alternative : 6ft VGA cons ole cable )

- Power cord X 1

- M6 s crew, cage nut & cup w asher X 8


The above package content is only for the single console models.

It varies with options such as KVM, SDI, audio & DC power.










5

1

6

7

2

8

3

9

4

1

LCD interch angeable module kit

2

Installation Slides

3

LCD membrane

4

Membrane switch (KVM option)

5

Micro switch fo r screen au to power off

10



6

K eyboard interchangeable module kit

7

Mouse interchangeable module kit

8

B lue Power LED

9

Front USB port f or device access ( USB Hub KVM only )

10

Molded front handle
