< 2.3 > On-screen Display Operation ( OSD )
M embrane Switch Funct ion
Turn the monitor on or off
Display the OSD menu
Act as an Enter key to select screen setting options
Scroll through menu options and adjust
the displayed co ntrol
Exit t he OSD screen
Go back to the previous on-screen sub-men u o r
main menu
Remark : All LED touch buttons in WHITE light.
The LED of Power tou ch button will flash continuously when there is no signal input.
1 All the LED touch buttons will au tom atically turn off after 10 minutes of idle status ( excep t the Power ).
2 Light up all membran e bu tton s, please press any button for 1 - 2 seconds ( excep t the Power ).
1 Picture
Picture mode : Standard / Vivid / Soft / User mode to choose
Brightness : Adjust background black level of the screen image
Contrast : Adjust the difference between the image background
(black level) and the foreground (white level)
Hue: Adjust the screen hue value
Saturation : Adjust the saturation of the image color
Picture size : Adjust the image size
Color temp : Standard / Cool / Warm / User to choose
Noise reduce : Reduce the noise of the image Sharpness
: Adjust the image from weak to sharp
