1 2
PACKAGE CONTENTS
DESCRIPTION
Riflescope Photon
Carrying case
User manual
Video cable
Cleaning cloth
Warranty card
The riflescope Photon is an original combination of a digital riflescope and daylight sight. The reticle has
illuminated dot with adjustable brightness. The riflescopes are equipped with 780/915 nm built-in eyesafe laser IR
Illuminators. The 915 nm IR operates in the invisible range which allows covert observation. The riflescopes can be
mounted using regular mounting brackets for day sights. The riflescope is designed for observation in the twilight or
in the nighttime but due to the use of CMOS array, the unit can be used in the day too. The lens cap has a light filter
which reduces image brightness. The riflescopes Photon is designed for hunting, sports shooting, security,
general observation.
FEATURES
3.5x/5x optical magnification
82 mm eye relief
Built-in eyesafe laser IR Illuminator (780 or 915 nm)
Ability to use any standard mounts for daylight sights
Reticle with illuminated red dot
Contrast image
Adjustable image brightness
External power supply
Video output – ability to use external recording equipment
Lightweight and compact
SKU 26321
Photon 5x42
* Max. detection range of an
object measuring 1.7x0.5 m
in natural night conditions
(0.05 lux, quarter moon).
Depending on the region of
sale.
Model
Optical characteristics
Magnification, x
Objective lens diameter, mm
Field of view, degree / m
Exit pupil, mm
Eye relief, mm
Click value, MOA (mm)
Close-up distance, m
Eyepiece dioptre adjustment, D
Max. detection range (built-in IR illuminator on), m/yds*
Electronic specifications
Type of array
Camera resolution, pixel
Resolution, lines/mm
Operational characteristics
Tube diameter, mm
Power supply (Battery type): riflescope/reticle
External power supply / Power consumption
Operation time with one set of recharg. batt. (IR off/on), hour
Degree of protection, IP code (IEC 60529)
Video output
Max. shock resistance
Operating temperature
Built-in IR Illuminator
Wavelength, nm
Equivalent power, mW
Safety class for laser equipment acc. to IEC 60825-1:2007
Output power for laser radiation, not more than
Dimensions, mm / inch
Approx. weight, kg / oz
ENGLISH
26323
Photon-V 5x42
**
5
42
4 / 7
8
82
1/4 (7)
1
-2 / +2.5
190 / 208
CMOS / 1/4"
500x582
36
30
3V (2xAA) / 3V (CR2032)
8.4-15V / 0.9W
4 / 3
IPX4
CCIR / EIA**
5000 Joules
-10 ºC … +50 ºC / +14 ºF... +122 ºF
780
150
1
Laser
13 mW
350x77x80 / 13.7x2.8x3.1
0.9 / 31.7
5
42
4 / 7
8
82
1/4 (7)
1
-2 / +2.5
150 / 164
CMOS / 1/4"
500x582
36
30
8.4-15V / 0.9W
4 / 3
IPX4
CCIR / EIA**
5000 Joules
915
150
1
Laser
20 mW
0.9 / 31.7
26324
Photon 3.5x42
26326
Photon-V 3.5x42
3.5
42
6.5 / 11
8
82
1/4 (7)
1
-2 / +2.5
160 / 175
CMOS / 1/3"
768x576
36
30
3V (2xAA) / 3V (CR2032)
8.4-15V / 0.9W
4 / 3
IPX4
CCIR / EIA**
5000 Joules
-10 ºC … +50 ºC / +14 ºF... +122 ºF
780
150
1
Laser
13 mW
350x77x80 / 13.7x2.8x3.1
0.9 / 31.7
3.5
42
6.5 / 11
8
82
1/4 (7)
1
-2 / +2.5
120 / 131
CMOS / 1/3"
768x576
36
30
8.4-15V / 0.9W
4 / 3
IPX4
CCIR / EIA**
5000 Joules
915
150
1
Laser
20 mW
0.9 / 31.7
For improvement purposes, design of this product is subject to change.
