ExaSAN A08S-PS User’s Manual
36
Appendix B
Specifications
CPU IOP 81341 800MHz
PCI Express One PCIe x 8
PCI One 64-bit PCIX-133
R6 support Yes
Disk
Disk interface SAS / SATAII
Disk channel 8
Disk interface chip LSI SAS 1068
Host
Host channel One PCIe x 4
Memory
Memory size 512 MB (up to 2 GB)
Battery backup Yes
Dimensions
Controller board L217.5 x W136 mm
Board PCB thickness 2.0mm
8 bay tower 175 (W) x 352.5 (D) x 394.6 (H) mm
Tower weight 11.12 kg
Operating parameters
Operating temperature 0
o
C~40
o
C
Operating humidity 5%~85%, Non-condensing
Storage humidity 5%~95%
Storage temperature -20
o
C~70
o
C
Power supply
Single power supply
(second power supply optional)
Input requirements 110V~240V, 47 ~ 63Hz
Wattage 300W x2
Fans
Hot-swappable fan Turbofan x 2
Noise dBA Boot up < 60 dB, Stable < 45dB
