ABOUT ColorRay MR Driver
1.2Stand Alone Mode
The Stand Alone Mode is engaged in by flipping the dip-switch 10 to the "OFF" position. And this mode
includes sub-modes with many functions, such as fade time, chasing speed, built-in programs.
1 2 3 4 5 6 7 8 9 10
ON RS
ON
OFF
1,2,4
3,4
1,3,4
2,3,4
1,2,3,4
1,2,3,4,5,6,7,8,9
1
2
1,2
3
1,3
2,3
1,2,3
4
1,4
2,4
DMX ADDRESS (SLAVE)
SWITCHES ON SWITCHES ON
(Dip Switch 10 = on)
START
CH#
START
CH#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
..
511
..
.. ..
.. ..
.. ..
1 2 3 4 5 6 7 8 9 10
ON RS
DMX is short for Digital Multiplex. This is a universal binary language used as a form of communication
between intelligent fixtures. Each dip switch represents a binary value.
1.Operation Guide
A DMX value(address) is set by combining the different dipswitches that will add up to the value you wish to
achieve, for example:
Setting DMX address for 21.
Flip switches1,3,&5 to the
"ON" position
Setting DMX address for 201.
Flip switches1,4,7,& 8 to the
"ON" position
Dipswitches# Value
1=1
3=4
5=16
=21
Dipswitches# Value
1=1
4=8
7=64
8=128
=201
In this mode, the dip-switch 10 is flipped to the "ON" position. And this switch sometimes used to activate
some fixture special functions.
Dip Switch 1 address equals 1
Dip Switch 2 address equals 2
Dip Switch 3 address equals 4
Dip Switch 4 address equals 8
Dip Switch 5 address equals 16
Dip Switch 6 address equals 32
Dip Switch 7 address equals 64
Dip Switch 8 address equals 128
Dip Switch 9 address equals 256
1.1 DMX Control Mode (DMX Addressing)
000
100
010
110
001
101
011
111
0%
100%
1 2 3 ON
FADE TIME
"0" = "OFF" position
"1" = "ON" position.
(Dip Switches 10 = off)
1) The Stand Alone Mode enables.
2) Thus, flip the dip-switch 1,2 & 3(12-way Function Dip Switch) to set a desired level for fade time.
1.2.1 Setting fade time
14%
28%
43%
57%
71%
86%
11 12
11 12
