Airbag System Components
Additional Information About Your Airbags
22
(9)
(1)
(3)
(11)
(5)
(4)
(13)
(14)
(5)
(4)
(6)
(10)
(15)
(8)
(17)
(16)
(17)
(16)
(8)
(2) (12) (7)
(1) Driver’s Front Airbag
(2) Passenger’s Front Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners
(5) Side Airbags
(6) Driver’s Seat Position Sensor
(7) Front Passenger’s Weight Sensors
(12) Front Passenger’s Weight Sensors/OPDS Sensors Control Unit
(13) Seat Belt Buckle Tensioners
(14) Rear Safing Sensor
(8) Front Impact Sensors
(9) Passenger Airbag Off Indicator
(10) Side Impact Sensors (First)
(11) Occupant Position Detection System (OPDS) Sensors
(15) Supplemental Restraint System (SRS) Indicator
(16) Side Impact Sensors (Second)
(17) Side Curtain Airbags
