HONDA 2011 Civic Coupe - Manual (Page 70)

If it comes on and stays on at any
other time, there is a problem with
the VSA system. Take your vehicle
to a dealer to have it checked.
Without VSA, your vehicle still has
normal driving ability, but will not
have VSA traction and stability
enhancement. See page
for more
information on the VSA system.
This indicator has three functions:
It flashes when VSA is active (see
page
).
It comes on as a reminder that you
have turned off the vehicle
stability assist (VSA) system.
It comes on along with the VSA
system indicator if there is a
problem with the VSA system.
This indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. See page
for more
information on the VSA system.
This indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page
).
This indicator comes on when you
set the cruise control. See page
for information on operating the
cruise control.
1.
2.
3.
224
224
282
282
282
If equipped
If equipped
If equipped If equipped
VSA Activation Indicator Vehicle Stability Assist
(VSA) System Indicator Cruise Main Indicator
Cruise Control Indicator
Instrument Panel Indicators
64
10/06/24 16:29:20 31SVA650_069
