2
ENERMAX MAXREVO Series Power Supply Specification
EMR1200EWT EMR1350EWT EMR1500EGT
AC Input Voltage
115-240VAC, 50-60Hz
(Maximum range: 100-264VAC, 47-63Hz)
220-240VAC, 50-60Hz
AC Input Current 12.5– 5.5A 14.5 – 6.5A 8.0 – 7.0A
DC Output
Rated Combined Rated Combined Rated Combined
3.3V 0-25A
140W
0-25A
140W
0-25A
140W
5V 0-25A 0-25A 0-25A
12V1 0-30A
1200W
(100A)
0-30A
1344W
(112A)
0-30A
1500W
(125A)
12V2 0-30A 0-30A 0-30A
12V3 0-30A 0-30A 0-30A
12V4 0-30A 0-30A 0-30A
12V5 0-30A 0-30A 0-30A
12V6 0-30A 0-30A 0-30A
-12V 0-0.5A 6W 0-0.5A 6W 0-0.5A 6W
5Vsb 0-4A 20W 0-4A 20W 0-4A 20W
Total Power 1200W 1350W 1500W
Peak Power 1440W 1620W 1650W
Protection Circuit
Over Current
Protection
DC Rail OCP trigger range
3.3V 30 – 45A
5V 30 – 45A
12V1/2/3/4/5/6 40 – 50A
(DC)
Under Voltage /
Over Voltage
Protection
DC Rail UVP trigger range OVP trigger range
3.3V 2.0 – 2.4V 3.9 – 4.5V
5V 3.3 – 3.7V 5.7 – 6.5V
12V1/2/3/4/5/6 8.5 – 9.5V 13.3 – 14.5V
-12V -8.5 – -9.5V -13.3 – -14.5V
(AC)
Under Voltage
Protection
Activated when AC input voltage < 70VAC.
Over Power
Protection
Activated when output power > 110 ~160% of rated max load.
Over
Temperature
Protection
Activated when PSU heat sink > 90 ~ 110 o C.
Short Circuit
Protection
Activated when any DC rails short-circuited.
Surge & Inrush
Protection
Sustain 2KV surge stroke.
Sustain up to 70A inrush current @ 240VAC at cold start.
ENVIRONMENT
Temperature
Operation ambient: 0~50 o C (for full rated output)
Storage ambient: -40~70 o C
Humidity
Operation: to 85% relative humidity, non-condensing at 25 o C
Storage: to 95% relative humidity, non-condensing at 50 o C
OTHERS
MTBF
> 100,000 hours at 70% of full rated load, 230VAC/50Hz, 25 o C
(MIL-HDBK-217F standard)
Dimension 150 (w) x 86 (h) x 180 (d) mm
Weight 2.25kg (without modular cables) ±50g
Safety UL/cUL(Level 6), TUV, CCC, GOST, CB, BSMI (1200/1350W)
EMC CE, FCC, KCC
