REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES ITEMS 2-3

AIR CLEANER COVER ASY

1

P021012110

1

COVER, AIR CLEANER

1

A232000390

2

SCREW 5X20

2

V253000100

3

FILTER, AIR

1

A226000360

4

SCREW 5X55

2

90010505055

5

PLATE, PREVENT

1

A244000010

6

CASE, AIR CLEANER

1

P021009590

7

INSERT

1

1

A239000050

8

PIPE, VENT

1

13201239331

9

PUMP, PURGE

1

12318139130

10

REPOWER BULK OPTION: 90014

PIPE, INTAKE - 3X5X80mm

1

V471001560

11

CARBURETOR

2

1

------------------

12

GASKET, INTAKE

1

1

V103000080

13

SCREW 5X25

2

90010605025

14

INSULATOR, INTAKE

1

A200000060

15

SHIELD, DEBRIS

1

A128000060

16

GASKET, INTAKE

1

1

V103000070

17

Footnotes

1: Also Included In GASKET KIT
2: See Carburetor Diagram For Additonal Information

99922200667

- 7 -

REVISED 09/22/09
