REMARKS DESCRIPTION QTY PART NUMBER ITEM
DRUM, CLUTCH 1 A556000490 1
INCLUDES ITEM 3 HANDLE BAR ASY 1 C080000001 2
LABEL, CAUTION 1 X505000920 3
GRIP, HANDLE 1 C403000050 4
BEARING, BALL 3 V713000000 5
SHAFT, GEAR - 7 TOOTH 1 C534000141 6
GEARCASE - UPPER 1 C531000150 7
BEARING, BALL 2 V712000000 8
CIRCLIP 3 V582000000 9
GEAR, SPUR - 48 TOOTH 1 V650000090 10
DOWEL PIN - 0.25x0.50 in 2 V624000020 11
SHAFT, GEAR - 10 TOOTH 1 C534000150 12
GEAR, SPUR - 44 TOOTH 1 V650000100 13
GASKET, GEAR CASE 1 V110000020 14
GEARCASE - LOWER 1 C531000160 15
BOLT 1/4-20 X 2 4 9507017200 16
BOLT 1/4-20 X 1-1/2 2 9507017150 17
DRIVESHAFT 1 C504000120 18
99922200667 - 21 - REVISED 09/22/09
Table of Contents Part Number Index
EA-410EU Earth Auger Handlebar Assembly, Gearcase
