Appendix Earthquake Sound
SPECIFICATIONS
• Number of channels:
16-Channels
• Power rating per channel:
(8-ohm load), all channels driven: 75 Watts RMS
• Frequency response measured at 1 watt with +/- 0.1 dB:
20 Hz to 20 kHz
• Channel separation: greater than 60 dB
• Maximum input voltage: 100mV – 2V (RMS)
• Input impedance: 19 kilo-ohms
• Total harmonic distortion - THD: 0.1%
• Signal to noise ratio measured: -83 dB
• Dimensions 16-Channel: (HxWxD)
6.5" (165.1mm) x 17" (431.8mm) x 17” (431.8mmmm)
• Weight :
44 lbs
FEATURES
• Short current protection, overload protection, Thermal protection
• Soft start
• Individual channel control
• BUS Input - BUS gain control
• LED Clipping indicators
• Bridgeable function (Bridgeable stable not lower than 4-Ohm)
• 220V AC and 110V AC selectable
• 12-Volt trigger
• Easy Stereo/Bridged binding post connections
