7
! do not apply too much pressure on the tool; let
the sanding surface do the work for you
- guide the tool parallel to the working surface and move
it in circles or in a cross pattern
- do not tilt the tool in order to avoid deep unwanted
sanding marks
- keep ventilation slots K 2 uncovered
• Sanding
- the amount of material removed is determined by the
speed of the sanding disc
- the speed of the sanding disc decreases relative to the
pressure applied to the tool
• Auxiliary handle
- loosen nut J almost completely
- push down handle H into desired position
- tighten nut firmly
APPlICATION ADVICE
• For determining the right grit table 7 can be used as
reference
! always test out first on a piece of scrap material
• Remove dust skirt D for sanding hard-to-reach places 8
• For more tips see www.skil.com
MAINTENANCE / SERVICE
• This tool is not intended for professional use
• Always keep tool and cord clean (especially ventilation
slots K 2)
- remove adhering sanding dust with a brush
! disconnect the plug before cleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skil.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol 9 will remind you of this when the need for
disposing occurs
DEClARATION OF CONFORMITY
• We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
60745, EN 61000, EN 55014, in accordance with the
provisions of the directives 2004/108/EC, 2006/42/EC,
2011/65/EU
• Technical file at: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹КБВЖО¹Ж¼½К
ЗЗ¾¼½Ж
И½К¹МБЗЖЛŵЖ¿БЖ½½КБЖ¿
НКЗИ½Ɠˁ˅ʿ˂ ʽ¼¹Ɠ
Д¹¾ БВГ¿К¹¹¾
ИИКЗО¹Д¹Ж¹¿½К
15.08.2013
NOISE/VIBRATION
• Measured in accordance with EN 60745 the sound
pressure level of this tool is 81 dB(A) and the sound
power level 92 dB(A) (standard deviation: 3 dB), and the
vibration 3,1 m/s² (hand-arm method; uncertainty
K = 1.5 m/s²)
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for different applications, or with different
or poorly maintained accessories, may significantly
increase the exposure level
- the times when the tool is switched off or when it is
running but not actually doing the job, may significantly
reduce the exposure level
! protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns
Ponceuse excentrique 7405
INTRODUCTION
• Cet outil est conçu pour le ponçage à sec du bois,
plastique, métal et mastic et des surfaces peintes
• Cet outil n’est conçu pour un usage professionnel
• Lisez et conservez ce manuel d’instruction 3
CARACTERISTIQUES TECHNIQUES 1
ElEMENTS DE l’OUTIl 2
A Support plateau
B Vis du support plateau
C Disque de ponçage
D Jupe à poussière
E Sac à poussière
F Interrupteur marche/arrêt
G Bouton de verrouillage de l’interrupteur marche/arrêt
H Poignée auxiliaire
J Ecrou papillon pour régler la poignée auxiliaire
k Fentes de ventilation
