11
Installation
Example of installation on the floor
mat or on the chassis
1. Place the amplifier where it is to be
installed. Insert the supplied tap-
ping screws (4
× 18 mm) into the
screw holes. Push on the screws with
a screwdriver so they make marks
where the installation holes are to
be located.
2. Drill 2.5 mm diameter holes at the
point marked, and install the ampli-
fier, either on the carpet or directly
to the chassis.
Replacing the terminal cover
1. Align the unit and terminal cover,
and insert the screw.
2. Tighten the screw with a 4 mm
hexagonal wrench (not supplied).
Drill a 2.5 mm diameter hole
Tapping-screws
(4
× 18 mm)
Floor mat
or chassis
Screw
Terminal Cover
