5. Web Configuration
The router can also be configured using the web-based configuration interface.
Follow the instructions below.
5.1. Accessing the Router
To access the web-based configuration interface:
1. Open the Internet Explorer (IE) browser and enter
http://192.168.2.1 .
2. In the Login page that is displayed, enter the username and password.
 The username and password of the super user are admin and 1234.
 The username and password of a common user are user and user.
Note:
In the Web configuration page, the settings can be saved permanently.
5.2. Status
In the navigation bar, click Status. In the Status page that is displayed
contains Device Info, System Log and Statistics.
5.2.1. Device Info
Choose Status > Device Info. The page that is displayed shows the current
status and some basic settings of the router, such as model number, software
version, LAN, WAN and ADSL information.
