3
Front
No. Description
1 IR LEDs for illumination in night mode
2 Day and night mode sensor for IR LED on/off control
3 Fixed focal lens
INSTALLATION
1. Before powering on the camera, find the screws in the package and use a
screwdriver to fix the sun shield onto the device’s main body.
2. Secure the wall mount bracket onto the wall, and then secure the camera
onto the bracket.
