28
If you need to use protected authentication credential, check „Use
protected authentication credential‟ box, and click „Import‟ to
load .pac credential file; to remove a loaded credential file, click
„Remove‟.
Session
Resumption
You can enable or disable session resumption here. If you don‟t
know if you should enable session resumption or not, please ask
your 802.1x authentication administrator.
ID \ Password
tab
Input 802.1x username (ID) and password and other information if it
is required here. Click „Show Password‟ to show the password you
typed.
Client
Certification
tab
Use this tab to select a local certificate from dropdown menu. If the
access point you wish to connect required a specific client
certificate, the certificate must be installed on your computer, and
you can select the certificate here.
Server
Certification
tab
Use this tab to use server-based certification. Please select a CA
(Certificate Authority) from dropdown menu. If intermediate
certificates are all owed, please select „Allow intermediate
certificates‟. Also, if you need to specify CA server‟s name, you can
specify it in „Server name‟ field. You can select „Server name must
match‟, so the CA server‟s name must be the same with the value
you set in „Server name‟ field; If only the domain name part of full
server name must the same with the value you set in „Server name‟
field, select „Domain name must end in specified name‟.
After you complete all information related to the access point, click „OK‟ to save the profile,
or click „cancel‟ to cancel adding a new profile.
If the profile is created, you will see the information in the Profile List.
