Edimax Technology HP-8501APg User Manual
Page 10
9
Connector
Description
POWER
Connect to power cord.
LAN (1-4)
Wireless Access Point is connected to a device through the corresponding port (1, 2, 3 or
4).
While data is sending or receiving by that port, corresponding LED will be flashing.
Antenna
Two kinds of antenna connecter available: fixed or R/SMA connecter.
2.4 Reset Switch
Connector
Description
Reset Switch
Press and hold this button for few seconds to clear all settings of this Wireless Access
Point
