1.3 Product Highlights

No pre-loaded software required - all you need is a browser like Internet Explorer

6 (and above, with plugin installed).

Supports 3 video resolutions: VGA (640 x 480), QVGA (320 x 240), and 160 x

120.

Anti-flicker function (eliminates flash caused by fluorescent lights, 50 / 60Hz

selectable).

Video control functions, like brightness and zoom-in / zoom-out.
Pan-tilt

control.

Wired and wireless network (802.11b / 802.11g) support, supports up to

100Mbps for wired network and 54Mbps for wireless network.

Wireless data encryption (WEP / WPA)
Supports DHCP and PPPoE protocol, you can also assign a fixed IP address to

the camera also.

Supports Dynamic DNS (used to allocate the IP camera’s Internet address,

when the ISP you’re using does not assign you with a fixed Internet address).

Supports UPnP, Windows XP (and above) will discover this IP camera in network

neighbor automatically.

Send captured picture by Email or FTP when motion is detected.
Configurable motion detection sensitivity (6 levels from most sensitive to least

sensitive).

Built-in real-time clock, date and time information will be recorded with every

captured picture / video clip (also supports auto time synchronization via network
time protocol).

Upgradeable firmware - enjoy new functions without buying a new camera!
Supports up to 4 users, and you can set different password to different user.
Usage and event logging.
