25
Step 1
On the Basic Wireless Settings page, set the WDS mode to be Lazy
Mode, set the same phy mode and encryp type with the peer AP, and
then enter the MAC address of the peer AP. After finishing the settings,
click the Apply button to apply the settings.
Step 2
Enter the Wireless Security/Encryption Settings page, set the
security mode of the HP-2002APN to accord with the peer AP.
2) Bridge Mode
In the bridge mode, you can use the HP-2002APN to connect to your router,
for extending wireless coverage. Meanwhile, it can also decrease the working
load of the AP that accesses the Internet. In that case, the wireless card does
not directly communicate with the wireless device that accesses the Internet,
but it directly communicates with the HP-2002APN.
Step 1
On the Basic Wireless Settings page, select the WDS mode to be
Bridge Mode.
Field Description
WDS
Mode
Select the Bridge Mode.
Phy
Mode
The physical modes in the drop down list include CCK,
OFDM, HTMIX, and GREENFIELD.
