Gembird SIS-PWM - Manual (Page 4)

4
SIS-PWM Silver Shield(TM) advanced
surge protector with power meter
All brands and logos are registered trademarks of their respective owners
• Computer measurements: voltage and current measuring (RMS, peak
values), power measuring (true, apparent, reactive), real and full energy
consumed during a time period (kWH)
• Measurements range: up to 250 VAC, 10 A (RMS), 2500 W, 22.000 kW a
year
• Working conditions: +10...40 Celsius degrees, below 90% humidity
• Measurements accuracy: ± 1% (within 40W-2500W power range)
• Max surge voltage 6000 V, spike current 13500 A
• Automatic circuit breaker: 10 A
• Resistance to short-circuits: 1.5 KV
• Dimenstions: 460 x 140 x 65 mm
• Net weight: 1.3 Kg
1. Introduction
Congratulations on purchasing the SIS-PWM. It is an advanced
surge protector with power metering features.
