12
CXS
GB
Vibration emission value a
h
(vector sum for three
directions) and uncertainty K measured in accor-
dance with EN 60745:
The specified emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary esti-
mates regarding vibration and noise loads during
operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with other
insertion tools or if not maintained adequately. Take
note of idling and downtimes of machine!
2
Symbols
3
Technical data
* Speed specifications with fully charged battery
pack.
4
Machine features
The specified illustrations appear at the beginning
of the Operating Instructions.
5
Intended use
Cordless drill suitable for
Wear ear protection.
Drilling in metall
a
h
=3,0 m/s
2
K = 1,5 m/s
2
Fastening
a
h
=4,0 m/s
2
K = 1,5 m/s
2
Warning of general danger
Risk of electric shock
Read the Operating Instructions/Notes!
Wear ear protection.
Wear protective gloves.
Wear protective goggles.
Do not throw in the household waste.
Cordless drill
CXS
Motor voltage
10.8 V
Idling speed*
1st gear
0 - 400 rpm
2nd gear
0 - 1200 rpm
Max. torque
soft/ hard material
10/ 16 Nm
Adjustable torque
0.2 - 2.4 Nm
Chuck clamping range
1 - 8 mm
Drill diameter max.
Wood/ Metal
12/ 8 mm
Tool holder in drill spindle
1/4 ’’
Weight without battery pack
with Centrotec
0.7 kg
Charger
MXC
Mains voltage (input)
220 - 240 V ~
Mains frequency
50/60 Hz
Charging voltage (output)
10.8 V=
Rapid charging
typ. 2.8 A
Charging times for
LiIon 1,5 Ah, 80 %/ 100 %
approx. 23/ 35 min
Permitted operating tempera-
ture range
-10 °C to + 40 °C
Temperature monitoring
via NTC-resistor
Safety class
/II
Battery pack
BP-XS
Voltage
10.8 V
Capacity
1.5 Ah
Number of cells
3
Permitted battery temperature
for charging
0 °C to + 45 °C
Weight
0.2 kg
[1-1]
Torque thumbwheel
[1-2]
Drilling symbol
[1-3]
Torque/drilling position marking
[1-4]
Gear switch
[1-5]
Right/left switch
[1-6]
On/Off switch
[1-7]
Belt clip
[1-8]
Button for releasing the battery pack
[1-9]
Bit store
[1-10]
LED lamp
[3]
Wall mount
Cordless drill
