Installation Guide ASV‑PV (DN 15‑50)
Heating Solutions VI.A1.I7.7O SMT/SI
❾
n
ASV‑PV DN 50
5 ‑ 25 20 ‑ 40 35 ‑ 75 60 ‑ 1.00
(kPa) (kPa) (kPa) (kPa)
0 25 40 75 1.00
1 24 39 73 98
2 23 38 71 96
3 22 37 69 94
4 21 36 67 92
5 20 35 65 90
6 19 34 63 88
7 18 33 61 86
8 17 32 59 84
9 16 31 57 82
10 15 30 55 80
11 14 29 53 78
12 13 28 51 76
13 12 27 49 74
14 11 26 47 72
15 10 25 45 70
16 9 24 43 68
17 8 23 41 66
18 7 22 39 64
19 6 21 37 62
20 5 20 35 60
Factory presetting
∆p setting range (kPa) kPa
5 ‑ 25 10
20 ‑ 40 30
35 ‑ 75 60
Factory presetting
∆p setting range (bar) bar
0.05 ‑ 0.25 0.1
0.20 ‑ 0.40 0.3
0.35 ‑ 0.75 0.6
0.60 ‑ 1.00 0.8
n
ASV‑PV DN 15 ‑ 40
5 ‑ 25 20 ‑ 40 35 ‑ 75
(kPa) (kPa) (kPa)
0 25 40 75
1 24 39 73
2 23 38 71
3 22 37 69
4 21 36 67
5 20 35 65
6 19 34 63
7 18 33 61
8 17 32 59
9 16 31 57
10 15 30 55
11 14 29 53
12 13 28 51
13 12 27 49
14 11 26 47
15 10 25 45
16 9 24 43
17 8 23 41
18 7 22 39
19 6 21 37
20 5 20 35
