Installation guide ame 25, ame 35 – Danfoss AME 35 User Manual
Page 5
55
Function test
The indicator light shows whether the
positioner is in operation or not. Moreover,
the indicator shows the control status and
faults.
Constant light
- normal operation
No light
- no operation or no power supply
Intermittent light (1 Hz)
- self adjusting-mode
Intermittent light (3 Hz):
- power supply too low
- insufficient valve stroke (<20 s)
- end-position cannot be reached.
Dimensions
❺
Installation Guide
AME 25, AME 35
Danfoss Heating
EI.96.A9.2V
DH-SMT/SI
