3M S40C - Manual (Page 26)

PICTURE-1 Menu
PICTURE-2 Menu
With the PICTURE-1 menu, the five items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
With the PICTURE-2 menu, the four items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
Item Description
COLOR BAL R Adjust Red Color Balance: Dark Light
COLOR BAL B Adjust Blue Color Balance: Dark Light
SHARPNESS Adjust Sharpness (for VIDEO/S-VIDEO): Clear Soft
COLOR
Adjust COLOR (for video/s-video/component video):
Dark
Light
TINT Adjust Tint (for video/s-video): Green Red
PICTURE-1 Menu
Item Description
V POSITION Adjust Vertical Position (for rgb): Up Down
H POSITION Adjust Horizontal Position (for rgb): Left Right
H PHASE
Adjust Horizontal Phase (for rgb/component video):
Right
Left
• Adjust to eliminate flicker.
H SIZE
Adjust Horizontal Size (for rgb): Large Small
• If the horizontal size adjustment is excessive, the image may not be displayed
correctly. In such a case, initialize H SIZE with the RESET button.
25
PICTURE-2 Menu
Example : PICTURE-1 Menu
(COLOR BAL R)
Example : PICTURE-2 Menu
(V POSITION)
MENU
: SELECT
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION COLOR BAL R
COLOR BAL B
SHARPNESS
COLOR
TINT
12
MENU
: SELECT
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION V POSITION
H POSITION
H PHASE
H SIZE
12
