24
3M™ Series 55 HVLP Automatic Spray Gun Parts Identification
IItem Description Replacement PN
1 Retaining Ring 91-043
2 Air Cap (Composite) 91-009-XXX
2* Air Cap (Aluminum) 91-071-XXX
3 Fluid Nozzle
4 Fluid Fitting 95-025
5 Autogun Body Assembly 95-028
6 Cylinder Seal (U-Cup) 95-018
7 Piston 95-031
8 O-Ring UH-768/5 (Pack of 5)
9 Needle Tip (Delrin®) 91-107-XXX/4 (Pack of 4)
10 Needle Shaft 95-033
11 Needle Return Spring
12 Cylinder Cap (Adjustable)
13 Stainless Steel Ball UH-610
14 Compression Spring 95-013
15 Set Screw UH-691/5 (Pack of 5)
16 Jam Nut UH-824
17 Needle Adjustment Screw 95-032
18 O-Ring
19 Air Manifold 95-030
20 Set Screw UH-612/5 (Pack of 5)
21 Flat Head Screw
22 Air Inlet Fitting
23 Philips Pan Head Screw
24 Valve Seal Ball
25 Snap Ring
26 Fan Valve Body 95-014
27 O-Ring
28 Hex Jam Nut
29 Valve Stem 95-036
30 Plug 95-077
31 O-Ring UH-1405/10 (Pack of 10)
32 Needle Guide
33 Compression Spring
34 Packing Nut
35 Seal Nut
36 Teflon® Seal 95-020/2 (Pack of 2)
37 Seal Housing 95-017
38 O-Ring UH-647/10 (Pack of 10)
39 Needle Cover 95-102
40 Fluid Inlet Fitting 80-932
41 Cylinder Cap (Adjustable) Assembly 95-040
42 Fan Control Assembly 95-042
43 Fluid Packing Kit 91-200
44 Universal Maintenance Kit 95-043
Note: For all part numbers with X, see page 37
* Denotes difference in material
