Fig 4. fig 3 – Tannoy V300 User Manual
Page 10
Number on Assembly View (Fig 3.)
Description
Quantity
1
Hanging Bracket
2
2
Cross Member
1
3
Pivot Stud
2
4
M10 Plain Washer
2
5
M8 Spring Washer
2
6
M10 Spring Washer
4
7
M10 x 30mm Screw
2
8
M8 x 20mm Screw
2
9
M10 x 30mm Screw
2
10
M10 Nyloc Nut
2
11
Friction Washer
2
12
30mm Square Blank Plug
2
Fig 4.
Fig 3.
