Hardware Component Specifications
Specification “S” Value “H” Value “MSA” Value
Operating temperature
range
10° C ~ 35° C (50° F
~ 95° F)
10° C ~ 35° C (50°
F ~ 95° F)
10° C ~ 35° C (50° F
~ 95° F)
Storage temperature range -40° C ~ +60° C (-
40° F ~ 158° F)
-40° C ~ +60° C (-
40° F ~ 158° F)
-40° C ~ +70° C (-
40° F ~ 158° F)
Operating humidity range 8 ~ 90% non-con-
densing
8 ~ 90% non-con-
densing
8 ~ 90% non-con-
densing
Storage humidity range 5 ~ 95% non-con-
densing
5 ~ 95% non-con-
densing
5 ~ 95% non-con-
densing
Power supply 260W AC power
supply [24-pin, (4-pin
= 12V)]
560W Hot-swap
redundant AC
power supply with
PFC [ 24-pin, (8-pin
= 12V) ]
Thermal control
260W AC power
supply with PFC
[ 24-pin, (4-pin =
12V) ]
Rated AC input voltage 100 ~ 240V,
50/60Hz, 5-3 Amp
100 ~ 240V, 60-
50Hz, 10-5 Amp
per power supply
module (two mod-
ules included in the
chassis)
100 ~ 240V, 60-
50Hz, 5-3 Amp
Rated input frequency 50 ~ 60 Hz 50 ~ 60 Hz 50 ~ 60 Hz
Rated input current 5A MAX 10A (115V) to 5A
(230V)
5A MAX
Rated output power 260W 560W 260W
Maximum rated BTU 1370 BTUs/Hr N/A (see specs
below)
N/A (see specs
below)
Nominal DC output: +3.3V 15.0A 21.0A 15.0A
Nominal DC output: +5V 25.0A 30.0A 25.0A
Nominal DC output: +12V 18.0A 42.0A 18.0A
Nominal DC output: -12V 1.0A 1.0A 1.0A
Nominal DC output: +5V
standby
2.0A 4.0A 2.0A
Regulatory (power supply) Power Supply Safety
/ EMC USA - UL
listed, FCC Canada
- CUL listed
Germany - TUV
Certified
Europe/CE Mark
EN 60950/IEC
60950-Compliant
EN 60950/IEC
60950-Compliant
UL Listed (USA)
CUL Listed (Can-
ada)
TUV Certified (Ger-
many)
USA - UL listed,
FCC
Canada - CUL listed
Germany - TUV
Certified
Europe/CE Mark
EN 60950/IEC
60950-Compliant
