EPSON Endeavor 4SX/25, 40X/33, and 4DX2/50
Video Memory
If the computer has 512KB of video memory, you can install
four 256K x 4 bit, 70ns, 20-pin DRAM DIP (Dual Inline
Package) chips to increase the video memory to 1MB. The
following table lists which DRAM DIP chips you can install
on the main system board.
Supported DRAM Chips
Manufacturer Part number
Mitsubishi® M5M44256BP-7
Toshiba® TC514256AP-70
Micron® MT4C4256-70
Hard Disk Drive Types
The table below lists types of hard disk drives you can use in
the computer. Check this table and your hard disk manual to
find the correct type number(s) for the hard disk drive(s)
installed in the computer. You need to enter the type
number(s) when you set the hard disk drive configuration in
the SETUP program.
Hard Disk Drive Types
Hard Disk Drive Types (continued)
If the computer has an Epson 120MB or 240MB hard disk
drive, select the appropriate type number from the table
below when you run the SETUP program.
Epson Hard Disk Drive Types
Type number Epson hard disk drive
39 120MB
34 240MB
Installation/Support Tips
Power
The computer has an input voltage selection switch on the
back panel to select between 115V, for USA and Canadian
use, and 230V, for use in other countries.
Mouse and Keyboard
When connecting the mouse and keyboard to the computer,
be careful to plug them into the proper ports. Although the
ports are physically identical, they are not interchangeable,
and damage may occur to the main system board if you plug
the connectors into the wrong ports
Installing Diskette Drives
Make sure that the drive type has been correctly selected in
the SETUP program.
4/1/93 EPSON Endeavor-7
