Optical
• Brightness: typical : 3000 lumens
• Imager DLP
• Resolution (native): XGA (1024x768 pixels)
• Resolution (maximum): SXGA (1280x1024 pixels)
• Aspect ratio: 4:3 native, 16:9
• Colors: 16.7 million
• Screen size (range): 27-300 inches
• Zoom / Focus: Manual
• Zoom ratio: 1.2: 1
• Projection lens: F (focal length): (2.4-2.6) (f =26.5-31.8 mm)
• Optional lenses: No
• Contrast ratio (peak): 2000:1
• Lamp: W, Type: 300W UHB
• Lamp life (average): 2000 hrs
ElEctrical
• Video compatibility: NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, SECAM
• HDTV: 480i, 480p, 576i, 576p, 720p, 1080i
• Keystone Correction: Vertical: 50˚
• Startup Screen: Customizable
• Noise level: normal (whisper): 41 (37) dB
• Feature set: Auto off,digital magnification, freeze, timer, mouse emulation
• Horizontal scan: 31.5-68.7 Khz
• Verticle scan: 50-85 Hz
• Power consumption: 430w
• Power supply: Universal: 100-240 VAC (50/60 Hz)
• Regulatory approvals: UL, cUL, FCC Part 15 Class A, CE, TUV, EN60950
• Operating temperature: 41- 95 F (5 - 35 C)
• Storage temperature: 14- 140 F (-10 - 60 C)
• Infrared Remote
sizE
• Dimensions (W x H x D): 10.2X2.9x3.3 (258x91x327 mm)
• Weight: 6.6lbs / 3 kg
Warranties
• Projector: 3 Years Standard
• Ultra Value Warranty available—includes free lamp and free loaner
while unit is repaired and expedited service.
• Lamp: 1 Year Prorated
accEssOriEs includEd
• Power Cords (3x - US, UK, Euro)
• RGB computer cable
• USB cable
• Audio cable
• Video cable
• S-Video cable
• DVI/Mini D sub
• Audio conversion adapter
• Storage case
• Full function remote control
• Multilanguage Operator’s Guide CD
OptiOnal accEssOriEs
• Ultra Value Warranty DX60 (DX60) 78-6969-9835-6
• Lamp for DX6 (LKDX60) 78-6969-9812-5
• Ceiling Mount, (CMDX50) 78-6969-9834-9
• 26-47" Adjustable Extension for Ceiling Mount (HE100) 78-6969-9698-8
Important Notice
Before using this product, you must evaluate it and determine if it is suitable for your intended
application. You assume all risks and liability associated with such use.
Warranty; Limited Remedy; Limited Liability
This product will be free from defects in material and manufacture for a period of 3 years
from the date of purchase. 3M MAKES NO OTHER WARRANTIES OR CONDITIONS
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. If this product is
defective within the warranty period, your exclusive remedy shall be, at 3M's option, to replace
or repair the 3M product. Except where prohibited by law, 3M will not be liable for any loss or
damage arising from this 3M product, whether direct, indirect, special, incidental or consequential
regardless of the legal theory asserted.
3M
™
Digital Projector DX60
Specifications subject to change without notice.
3M is a trademark of 3M Company. Used under license in Canada. All other trade names referenced
are the service marks, trademarks, or registered trademarks of their respective companies.
1-800-328-1371 www.3m.com/meetings
Hg—LAMP CONTAINS MERCURY. Manage in accord with disposal laws. See www.lamprecycle.org
or call 1-800-328-1371 (USA), 1-800-364-3577 (Canada). For product disposal see www.eiae.org
(USA) or www.epsc.ca (Canada).
3 Innovation
Note: These sizes are +10 percent. This is due to variations in the manufacture of the lens.
If you are close to one of the endpoints you should verify with your unit that the image is
the proper size at the proper distance.
Projection distance charts for X80 long throw and X80 short throw lens are available at
www.3m.com/meetings.
