FSG2200HNU
Data
FXS
FXS
STB
NAS
CATV (Activate by
FTU2000/3000)
0
8
5
2
#
9
6
3
1
4
7
*
0
8
5
2
#
9
6
3
1
4
7
*
Home/Office
SIP core
Internet
CATV
VOD
Server
TV, PPV, Radio
Head-end
CATV
Transmitter
Fiber Switch
Single Fiber for data
Single Fiber for CATV
Coax
PW
SYS
AL
50
49
ES-2048
2
14
5
17
20
22
25
42
3
45
4
1000 10
0
LNK
ACT
LNK
ACT
Features of the FTU
• Wall-mounted support
• 2 fibers capacity
• Fiber cable diameter:
φ3 to φ8 mm
• Fiber cable length: 0.5 meters ~ 3 meters
• SC/APC simplex connector support
• Together work with FSG2000 series FTTH CPE
• CATV RF output through Coax (FTU2000,
FTU3000)
• WDM feature integrated: CATV wavelength
1550 nm (FTU3000)
Physical Specifications
• Item weight:
FTU2000: 465 g
• Item dimensions:
FTU2000: 254 (W) x 153.9 (D) x 49 (H) mm
(10 (W) x 6.06 (D) x 1.92 (H) inches)
• Item and package weight:
FTU2000: 806.6 g (1.78 lb)
• Packing dimensions:
FTU2000: 326 (W) x 184 (D) x 91(H) mm
(12.83 (W) x 7.24 (D) x 3.58 (H) inches)
Environmental Specifications
Operating Environment
• Temperature: 0°C ~ 40°C
• Humidity: 20% ~ 85% RH (non-condensing)
Storage Environment
• Temperature: -25°C ~ 65°C
• Humidity: 20% ~ 90% RH (non-condensing)
Certification
• Safety: EN60950-1
• EMI : CE
Rear Panel
Compatible Model
Specifications
Application Diagram
ON/OFF
POWER
POWER
RESET
CATV
ETHERNET
USB1
USB2
PHONE
FSG
G2200HN
FTU Series
Feature Support
FTU1000* Fiber
Termination
Unit
FTU2000 Fiber
Termination
Unit,
CATV
FTU3000* Fiber
Termination
Unit,
CATV,
WDM
*Future Release
