ZyXEL Communications P-971M - Manual (Page 2)

Cable Modem
p-971m
Specifications
Standard Compliance
• DOCSIS 1.0/1.1/2.0 compliant
• IEEE 802.3u
• USB 1.1
Security
• BPI, BPI+
• DOCSIS Packet Filter
Management
• CLI (Command Line Interface) diagnostics Interface
• SNMP V1, V2 & V3
• Remote Status Monitoring
• Up to 32 Users (1 via USB and up to 31 via Ethernet
or 32 users on Ethernet)
Hardware Specification
Downstream
• Operating Frequency Range: 88 MHz to 860 MHz
• Channel Bandwidth: 6 MHz
• Input Impedance: 75ohms (Nominal)
• Modulation: 64QAM or 256QAM
• Maximum Data Rate: 38 Mbps
• Symbol Rates:
64QAM (5.069 Msym/s) 256QAM (5.361 Msym/s)
• Operating Level Range: -15 dBmV to +15 dBmV
Upstream
• Operating Frequency Range: 5 MHz to 42 MHz
(edge to edge)
• Bandwidth: 200 KHz/400 KHz/800 KHz/1.6 MHz/
3.2 MHz /6.4* MHz
• Output Impedance: 75 ohm (Nominal)
• Modulation: 8*/16/32*/64*/128* QAM or QPSK
• Maximum Data Rate: 30 Mbps**
• Symbol Rates: 160, 320, 640, 1280, 2560 and
5120* ksym/s
• Operating Level Range:
- A-TDMA: +8 to +54 dBmV (32QAM, 64QAM)
+8 to +55 dBmV (8QAM, 16QAM)
+8 to +58 dBmV (QPSK)
- S-CDMA: +8 to +53 dBmV (all modulations)
Environmental Specification
Operating Temperature: 5 °C ~ 50°C
• Operating Humidity: 10% ~ 90% RH
• 12VAC, 1A
Physical Specification
• 180(W) x 125(D) x 30(H) mm
Certification
• FCC, CE
* With A-TDMA or S-CDMA enabled CMTS
** Speed of 30Mbps is attainable only with A-TDMA or
S-CDMA technology.
65-100-097101G 09/05
