MIB Information
• RFC1213 MIB II
• RFC1493 Bridge MIB
• RFC1643 Ethernet MIB
• RFC1757 RMON group 1, 2, 3, 9
• RFC2011 IP MIB
• RFC2012 TCP MIB
• RFC2013 UDP MIB
• RFC2233 ifVHCPacketGroup
• RFC2674 VLAN MIB
• RFC2925 PING-MIB and TRACEROUTE-MIB
• ZyXEL Private MIB
Hardware Specifications
• Support of auto-negotiation
• Support of auto MDI/MDI-X
• Console: D-Sub 9 pin Female (DCE)
• Management: One out-of-band management
RJ-45 port
• Ports: 24 10/100Base-T, RJ-45 ports,
2 1000Base-T, RJ-45 ports and 2 dual-personality
GbE ports (RJ-45 or SFP open slots)
Physical Specifications
ES-2724 (28 ports)
• 24 10/100 ports + 2 1000Base-T ports + 2 Dual-
personality GbE ports
• Dimensions: 438 (W) x 270 (D) x 44.45 (H) mm
• Weight: 4.0 Kg
Power Requirements
• Input voltage of AC: 100-240VAC, 50/60Hz
• Max power rating of AC: 60 Watt
• Backup power supply into 12V DC
Environmental Specifications
• Operating temperature: 0 °C ~ 45°C
• Storage temperature: -25 °C ~ 70°C
• Operating humidity: 10% ~ 90%,
(non-condensing)
Safety
• UL 60950-1
• CSA 60950-1
• EN 60950-1
• IEC 60950-1
* EMS supports for future enhancement.
Operational Information
Gigabit Transceiver (Optional) Gigabit Transceiver (Optional)
SFP-SX
SFP-LX-10
SFP-BX1310-10
SFP-BX1490-10
SFP-LHX1310-40
SFP-ZX-80
LC
LC
LC
LC
LC
LC
Multi-mode
Single mode
Single mode
Single mode
Single mode
Single mode
850 nm
1310 nm
1310 nm (TX)
1490 nm (RX)
1490 nm (TX)
1310 nm (RX)
1310 nm
1550 nm
500 m
10 km
10 km
10 km
40 km
80 km
91-010-064001B
91-010-065001B
91-010-152001B
91-010-153001B
91-010-068001B
91-010-070001B
4718937420308
4718937420292
4718937504527
4718937504510
4718937420452
4718937420469
Distance EAN Code P/N Mode Connector Type Wavelength Model Name
