5
1. Hob Top
2. Rapid Burner
3. Semi-rapid Burners
4. Auxiliary Burner
5. Control knob for back right burner (semi-rapid)
6. Control knob for back left burner (semi-rapid)
7. Control knob for front left burner (rapid)
8. Control knob for front right burner (auxiliary)
9. Electric Ignition Push Button
Description of the Hob
INSTALLATION
Any gas installation must be carried out by
a registered CORGI installer, and in
accordance with existing rules and
regulations.
The relevant instructions are to be found in the
second section of this manual.
Please, ensure that, once the hob is
installed, it is easily accessible for the
engineer in the event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is
important to remove any protective
materials, which were put on in the factory.
1
2
3
3
4
8
7
6
5
9
