omni.net Plus/D Quick Start Guide
1-2
Front Panel LEDs
LED Function Active Description
PWR P o w e r L E D On W h e n t h e p o w e r i s t u r n e d O N .
LNK L i n k L E D On
Blinking
W h e n t h e l i n k w i t h t h e l o c a l I S D N s w i t c h i s a c t i v e .
W h e n a t t e m p t i n g t o m a k e a c o n n e c t i o n .
B1 B 1 C h a n n e l On W h e n t h e B 1 c h a n n e l i s e s t a b l i s h e d .
B2 B 2 C h a n n e l On W h e n t h e B 2 c h a n n e l i s e s t a b l i s h e d .
AA Auto - A n s w e r On
Blinking
W h e n y o u r I S D N T A i s i n A u t o A n s w e r m o d e .
W h e n y o u r T A r i n g s .
CP C o m p r e s s i o n On When Data Compression is being used over one or more
of the B Channels. Compression types are Hi/fn LZS
(formerly Stac) for PPP connections, and V.42bis for
V.120 or X.75 connections.
DTR Data Terminal
R e a d y On W h e n t h e D T E o r c o m p u t e r c o n n e c t e d t o t h e D T E
p o r t s i g n a l s t h a t i t i s r e a d y f o r c o m m u n i c a t i o n b y
establishing the RS - 2 3 2 l i n k .
DSR D a t a S e t
R e a d y On When the modem is ready for communication with the
DTE.
RTS Request To Send On When the DTE has data to be sent to the remote modem.
The RTS signal is used in Hardware Handshaking.
CTS Clear To Send On When the modem is ready to receive data from the
remote modem. The CTS signal is used in Hardware
Handshaking.
TX Transmit Data Blinking W h e n t h e D T E / C o m p u t e r t r a n s m i t s d a t a t o t h e
D T E p o r t .
RX R e c e i v e D a t a On W h e n t h e D T E / C o m p u t e r r e c e i v e s d a t a f r o m t h e
D T E p o r t .
Phone 1 (for omni.net
Plus only)
On When the POTS port 1 telephone/handset is off-hook.
Phone 2 (for omni.net
Plus only)
On When the POTS port 2 telephone/handset is off-hook.
