16
GB
Door Reversal
Should the setting-up place or handling demand it,
door-opening direction can be refitted from right-
handed to left-handed.
Appliances on the market are right-handed.
Following operations are to be done on the basis of
figures and explanations:
1. To perform the operations listed below it is
recommended to ask another person for help who
safely can hold the doors while performing the
operations.
2. Disconnect the appliance from the electricity
supply.
3. Open the doors and dismount the double door
hinge (a,b) by removing the screws (2 pieces) (c).
(fig. 2)
4. Take off the double door hinge (a,b,c) by gradually
removing it from the cabinet, slightly tilting both
fig. 1.
In the bag of the accessories there are two
spacers which must be fitted in the two top
corners.
Slacken the screws and insert the spacer under the
screw head, then re-tighten the screws.
Levelling the Appliance
When positioning the appliance ensure that it stands
level. This can be achieved by two adjustable feet at
the bottom in front.
Do not stand the appliance next to a source of heat
such as a radiator or cooker.
Ventilation Requirements
The appliance must have adequate ventilation to
ensure correct operation.
Diagram shows the ventilation requirements when
installed:
A Under a cupboard.
B When freestanding
